• Innovative indicator light bar with reflex lens and fancy chromed trim bezel.
• Stop (brake) , Indicator (Tail) and Turn functions combined, ideal to use as an identification light bar as well as a high mount third brake light for trailers
• 11 SMD LEDs, super-bright and long life span up to 50,000 hours
• PC lens and housing, ultrasonically welded together to ensure a permanent and water proof seal.
• LEDs sealed by epoxy and circuit board coated with conformal coating for excellent moisture and environmental protection
• Red color meets DOT FMVSS 108/SAE requirements for Stop, Tail and Indicator functions.
• Rated for 12V, tested to 13.8V
• Also available in multi-voltage 10~30V operating range or 24V by special order
Part No. |
Description |
Input Voltage |
Lighting Color |
LED Count |
Current Draw (mA) at 13.8V |
116211RL |
Light Only w/o Bezel, Red |
12V |
Red |
11 |
15/250 mA |
116211CL |
Light Only w/o Bezel, Clear |
12V |
White |
11 |
15/100 mA |
116211R |
Light Kit w/Bezel, Red |
12V |
Red |
11 |
15/250 mA |
116211C |
Light Kit w/Bezel, Clear |
12V |
White |
11 |
15/100 mA |
116211CR |
Light Kit w/ Bezel, Clear/Red |
12V |
Red |
11 |
15/250 mA |
116211RM |
Light Kit w/Bezel RED, Multi-voltage |
12~24 V |
Red |
11 |
15/250 mA |
116211CM |
Light Kit w/Bezel Clear, Multi-voltage |
12~24 V |
White |
11 |
15/100 mA |
